Tile Leveling Products
LITE LEVEL®
single elements
LITE LEVEL® is a new generation of leveling system for indoor tiles.
The cylinder is made of recycled plastic material and is available in bags of 50 pieces.
LITE LEVEL®works with the entire Dakota range of screw spacers:
- Linear spacer Screws for 1, 1.5, 2, 2.5, 3 and 4mm grout joints (³⁄₆₄, ¹⁄₁₆, ⁵⁄₆₄, ⁷⁄₆₄, ⅛ and ⁵⁄₃₂'').
- Cross and “T” spacer Screws for 1, 2 and 3mm grout joints (³⁄₆₄, ⁵⁄₆₄ and ⅛'').
An anti-scratch pad with a cross shape is available as an optional extra.
LITE LEVEL® is available in component form, in bags of 50 pieces or as a kit of 50 cylinders and 100 Linear screws.
The cylinder is made of PP (Polypropylene), and the spacer screws are made of HD-PE (Polyethylene).
Download Legend
PDF GREEN= Specification Sheet
PDF RED = Technical Datasheet
PDF GREEN= Specification Sheet
PDF RED = Technical Datasheet
| Code | Product | Size mm (in.) | Bag | Pkg. | Pallet Qty. | UM | |
|---|---|---|---|---|---|---|---|
| TER04-4450DK | Lite Level® Cylinder only | - | 50 pcs. | 10 bags | 150 bags | bag | |
| TER04-4410DD | Cross anti-scratch pad | - | 50 pcs. | 10 bags | 300 bags | bag | |
 | TER04-4401DK | Linear screw for h. 3 to 24mm (⅛ to 1 ⁵⁄₁₆'') | 1 (³⁄₆₄) | 100 pcs. | 25 bags | 375 bags | bag |
 | TER04-44015DK | Linear screw for h. 3 to 24mm (⅛ to 1 ⁵⁄₁₆'') | 1.5 (¹⁄₁₆) | 100 pcs. | 25 bags | 375 bags | bag |
 | TER04-4402DK | Linear screw for h. 3 to 24mm (⅛ to 1 ⁵⁄₁₆'') | 2 (⁵⁄₆₄) | 100 pcs. | 25 bags | 375 bags | bag |
 | TER04-44025DK | Linear screw for h. 3 to 24mm (⅛ to 1 ⁵⁄₁₆'') | 2.5 (⁷⁄₆₄) | 100 pcs. | 25 bags | 375 bags | bag |
 | TER04-4403DK | Linear screw for h. 3 to 24mm (⅛ to 1 ⁵⁄₁₆'') | 3 (⅛) | 100 pcs. | 25 bags | 375 bags | bag |
 | TER04-4404DK | Linear screw for h. 3 to 24mm (⅛ to 1 ⁵⁄₁₆'') | 4 (⁵⁄₃₂) | 100 pcs. | 25 bags | 375 bags | bag |
| TER04-4421DK | “X” screw for h. 3 to 24mm (⅛ to 1 ⁵⁄₁₆'') | 1 (³⁄₆₄) | 100 pcs. | 25 bags | 375 bags | bag | |
| TER04-4422DK | “X” screw for h. 3 to 24mm (⅛ to 1 ⁵⁄₁₆'') | 2 (⁵⁄₆₄) | 100 pcs. | 25 bags | 375 bags | bag | |
| TER04-4423DK | “X” screw for h. 3 to 24mm (⅛ to 1 ⁵⁄₁₆'') | 3 (⅛) | 100 pcs. | 25 bags | 375 bags | bag | |
| TER04-4431DK | “T” screw for h. 3 to 24mm (⅛ to 1 ⁵⁄₁₆'') | 1 (³⁄₆₄) | 100 pcs. | 25 bags | 375 bags | bag | |
| TER04-4432DK | “T” screw for h. 3 to 24mm (⅛ to 1 ⁵⁄₁₆'') | 2 (⁵⁄₆₄) | 100 pcs. | 25 bags | 375 bags | bag | |
| TER04-4433DK | “T” screw for h. 3 to 24mm (⅛ to 1 ⁵⁄₁₆'') | 3 (⅛) | 100 pcs. | 25 bags | 375 bags | bag |
LITE LEVEL®
kits and accessories
| Code | Product | Size mm (in.) | Bag | Pkg. | Pallet Qty. | UM | |
|---|---|---|---|---|---|---|---|
| TER04-4450S1 | Lite Level® Kit - 100 screws, 50 cylinders | 1 (³⁄₆₄) | 1 box | box | 80 boxes | box |
| TER04-4450S15 | Lite Level® Kit - 100 screws, 50 cylinders | 1.5 (¹⁄₁₆) | 1 box | box | 80 boxes | box |
| TER04-4450S2 | Lite Level® Kit - 100 screws, 50 cylinders | 2 (⁵⁄₆₄) | 1 box | box | 80 boxes | box |
| TER04-4450S25 | Lite Level® Kit - 100 screws, 50 cylinders | 2.5 (⁷⁄₆₄) | 1 box | box | 80 boxes | box |
| TER04-4450S3 | Lite Level® Kit - 100 screws, 50 cylinders | 3 (⅛) | 1 box | box | 80 boxes | box |
| TER04-4450S4 | Lite Level® Kit - 100 screws, 50 cylinders | 4 (⁵⁄₃₂) | 1 box | box | 80 boxes | box |
LINEAR APPLICATION
Indicative consumption - Example 1
Indicative consumption - Example 1
LINEAR APPLICATION
Indicative consumption - Example 2 (using X-Screws at corners)
