Hercules 150 extra high profile
Pedestal System & Risers - 150mm to 270mm
(6'' to 10⅝'')
Hercules pedestal support for outdoor flooring, with adjustable height from 150mm to 270mm (6'' to 10⅝''). Each pack contains the complete disassembled support with base, screw and fixed or self-leveling head (up to 5%) for paving with 4 removable tabs for 4mm (⁵⁄₃₂'') joints, or for joist support with a single securing fin. The heads are equipped with integrated anti-noise rubber inlays.
The pedestals can be adjusted from below by rotating the base and head or, in the case of paver installations, the finalization of the adjustment of the support takes place from above with the pavers installed, using the special key.
Available versions
with fixed head:
- paver support with fixed head with 4 spacer tabs of 4mm (⁵⁄₃₂") thickness
- joist support with fixed head with 1 tab for decking and flooring
with self-leveling head:
- paver support with self-leveling head with 4 spacer tabs of 4mm (⁵⁄₃₂") thickness
- joist support with self-leveling head with 1 tab for decking and flooring
The base includes water drainage channels.
Made of recycled PP (polypropylene).
Used in external areas for roof gardens, terraces, pavements and decks.
| Code | Product | Size mm (in.) | Pk | Pallet Qty. | UM |
|---|---|---|---|---|---|
| TER09-1183/4F150 | Hercules 150 Fixed Head Paver Support - 4mm (⁵⁄₃₂'') spacer tabs | 150mm to 270mm (6'' - 10⅝'') | 15 pcs. | 120 pcs. | 1 pc. |
| TER09-1183/1F150 | Hercules 150 Fixed Head Decking Support with 1 fixing tab | 150mm to 270mm (6'' - 10⅝'') | 15 pcs. | 120 pcs. | 1 pc. |
| TER09-1183/4L150 | Hercules 150 Self-leveling Head Paver Support - 4mm (⁵⁄₃₂'') spacer tabs | 150mm to 270mm (6'' - 10⅝'') | 15 pcs. | 120 pcs. | 1 pc. |
| TER09-1183/1L150 | Hercules 150 Self-leveling Head Decking Support with 1 fixing tab | 150mm to 270mm (6'' - 10⅝'') | 15 pcs. | 120 pcs. | 1 pc. |
| TER09-1183/P120 | 01 Hercules Extender for Hercules 94 & 150 | 120mm (4¾'') | 20 pcs. | 300 pcs. | 1 pc. |
| TER09-1183CHI | 02 Hercules Adjustment key for paver pedestals | - | 12 pcs. | - | 1 pc. |
