Outdoor Flooring Products

Hercules 94 high profile

Pedestal System & Risers - 94mm to 150mm
(3¹¹⁄₁₆'' to 6'')weight symbol

Hercules pedestal support for outdoor flooring, with adjustable height from 94mm to 150mm (3¹¹⁄₁₆'' to 6''). Each pack contains the complete disassembled support with base, screw and fixed or self-leveling head (up to 5%) for paving with 4 removable tabs for 4mm (⁵⁄₃₂'') joints, or for joist support with a single securing fin. The heads are equipped with integrated anti-noise rubber inlays.

The pedestals can be adjusted from below by rotating the base and head or, in the case of paver installations, the finalization of the adjustment of the support takes place from above with the pavers installed, using the special key.

Available versions

    with fixed head:

  • paver support with fixed head with 4 spacer tabs of 4mm (⁵⁄₃₂") thickness
  • joist support with fixed head with 1 tab for decking and flooring

    with self-leveling head:self-level-indicator

  • paver support with self-leveling head with 4 spacer tabs of 4mm (⁵⁄₃₂") thickness
  • joist support with self-leveling head with 1 tab for decking and flooring

The base includes water drainage channels.

Made of recycled PP (polypropylene).

Used in external areas for roof gardens, terraces, pavements and decks.

Hercules 94 Paver Pedestal
Hercules 94 Joist Pedestal
CodeProductSize mm (in.)PkPallet Qty.UM
TER09-1183/4F94Hercules 94 Fixed Head Paver Support - 4mm (⁵⁄₃₂'') spacer tabs94mm to 150mm
(3¹¹⁄₁₆'' - 6'')
20 pcs.160 pcs.1 pc.
TER09-1183/1F94Hercules 94 Fixed Head Decking Support with 1 fixing tab94mm to 150mm
(3¹¹⁄₁₆'' - 6'')
20 pcs.160 pcs.1 pc.
TER09-1183/4L94Hercules 94 Self-leveling Head Paver Support - 4mm (⁵⁄₃₂'') spacer tabs94mm to 150mm
(3¹¹⁄₁₆'' - 6'')
20 pcs.160 pcs.1 pc.
TER09-1183/1L94Hercules 94 Self-leveling Head Decking Support with 1 fixing tab94mm to 150mm
(3¹¹⁄₁₆'' - 6'')
20 pcs.160 pcs.1 pc.
TER09-1183/P12001 Hercules Extender for Hercules 94 & 150120mm
(4¾'')
20 pcs.300 pcs.1 pc.
TER09-1183CHI02 Hercules Adjustment key for paver pedestals-12 pcs.-1 pc.
Download Legend
PDF GREEN= Specification Sheet
PDF RED = Technical Datasheet
Decking - Fixed Head
Decking - Self-Leveling
Decking - Fixed Head
Decking Self-Leveling
Download Legend
PDF GREEN= Specification Sheet
PDF RED = Technical Datasheet
Paving - Fixed Head
Paving - Self-Leveling
Paving - Fixed Head
Paving - Self-Leveling

Accessories

Hercules height extender
01
Dakota Arkimede™ 50mm (2") height extender
02
