The "Standard" drainage inspection chambers, also known as catch basins or catch pits, are available in 200 and 300 mm (8" and 12") square in gray color.
Main characteristics:
Materials: Made of PP (polypropylene).
Use: Used as an alternative to traditional concrete catch basins for rain and storm water collection.
Code | Product | Size mm (in.) LxWxD | Pkg. | Pallet Qty. | UM |
---|---|---|---|---|---|
POZ01-1372E | Catch-Pit Standard Gray | 200 x 200 (8" x 8") | 1 pc. | 180 pcs. | 1 pc. |
POZ01-1373E | Catch-Pit Standard Gray | 300 x 300 (12" x 12") | 1 pc. | 48 pcs. | 1 pc. |
Extra Large catch-pit, dimensions: 735 x 735 x 650 mm (28" x 28" x 25½").
Main characteristics:
Material Made of PP (polypropylene).
Use: Used as a valid alternative to traditional concrete wells and particularly suitable for housing hydraulic and/or electrical devices for earthed systems. The Seventy manhole is the largest on the market and, unlike traditional concrete manholes, it is produced with a removable bottom and can be lifted by a person rather than by a crane!
The cover is a PP reinforced “plate” with 5 fiber-reinforced beams, laterally interlocked on the underside. The external surface is fitted with inserts of non-slip rubber and a pair of ergonomic retractable handles.
Capacity: 35 KN (approx. 3.500 kgs / 7,700 lbs).
Material: Cover made of PP (polypropylene), fiber-reinforced nylon and rubber. Frame made of PP (polypropylene).
Use: Used to cover the Catch-Pit, allowing inspection and providing an excellent alternative to traditional concrete catch-pit covers.
Code | Product | Size mm (in.) LxWxD | Pkg. | Pallet Qty. | UM |
---|---|---|---|---|---|
POZ01-1370 | Gray 'Seventy' Catch-pit | 735 x 735 x 650 (27½ x 27½ x 25½) | 1 pc. | 8 pcs. | 1 pc. |
POZ02-7070M | Gray Cover with Double Handle for 'Seventy' Catch-pit | 700 x 700 (27½ x 27½) | 1 pc. | 24 pcs. | 1 pc. |
POZ02-7070MV | Green Cover with Double Handle for 'Seventy' Catch-pit | 700 x 700 (27½ x 27½) | 1 pc. | 24 pcs. | 1 pc. |
POZ04-7070T | Gray Frame for 'Seventy' Catch-pit | 700 x 700 (27½ x 27½) | 1 pc. | 19 pcs. | 1 pc. |
POZ04-7070TV | Green Frame for 'Seventy' Catch-pit | 700 x 700 (27½ x 27½) | 1 pc. | 19 pcs. | 1 pc. |
